  • 16 FDB fibra optical terminal closure fiber optic termination box
  • 16 FDB fibra optical terminal closure fiber optic termination box
  • 16 FDB fibra optical terminal closure fiber optic termination box
  • 16 FDB fibra optical terminal closure fiber optic termination box
16 FDB fibra optical terminal closure fiber optic termination box 16 FDB fibra optical terminal closure fiber optic termination box 16 FDB fibra optical terminal closure fiber optic termination box 16 FDB fibra optical terminal closure fiber optic termination box

16 FDB fibra optical terminal closure fiber optic termination box

  • Product Item:N-01-16
  • Type: fiber optic termination box
  • Application: wall/pole mounting
  • Certification: RoHs , ISO 9001
  • Material: Reinforced thermoplastic
  • Inquiry Send Email

    Description

    connectors.
    Its sealing system is mechanical.
    It supports two configurations: up to two splice trays with a capacity of up
    to 16 fusions each, and a tray with up to 16 positions for adapters and up to two
    splitters storage; OR 4 splice trays.
    It accepts the incoming cable with diameter up to 15 mm through its oval port -
    which has 2 holes for cables from 8 to 15 mm diameter and 2 holes for cables from 6
    to 8 mm diameter, therefore it allows the derivation of the distribution cable. It
    supports up to 16 output drop cables, that may be round with diameters from 4.5 to
    5.3 mm or flat with dimensions 3.0 and 2.0 mm
    It accommodates 11 loose tubes of 1,5 m in length and 1.9 mm of diameter

    Product Description

    Specification

    Size 300 (height) x 220 (width) x 100 (depth) mm
    Body material Reinforced thermoplastic
    Color Black
    Weight 4.5 kg
    Input cable diameter 2 ports for cables from 8 to 15 mm
    Distribution cable diameter 2 ports for cables from 6 to 8 mm
    Drop cables dimensions Circular cables: 16 cables from 4.5 to 5.3 mm
    Flat cables: 16 cables with 2.0 x 3.0 mm
    IP Protection Degree 55
    Operation Temperature -25°C to 75°C
