Description
Definition
Planar light-wave circuit splitter (PLC Splitter) is a type of optical power management device that is fabricated using silica optical wave-guide technology.It is used to split a fiber optic beam into several beams at a certain splitting ratio.It is an important passive device in passive optical network.
Product Features
- Low Insertion loss
- Low PDL
- Excellent channel-to-channel uniformity
- High return loss and Good repeatability
- Wide wavelength range
Applications
- LAN, WAN and Metro Networks
- FTTH project & FTTX Deployments
- CATV System
- GPON, EPON
- Fiber Optic Test Equipment
- Data-base Transmit Broadband Net
Compliance
- Telcordia GR-1209-CORE-2001
- Telcordia GR-1221-CORE-1999
- YD-T2000.1-2009
- RoHS
| Parameters | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | 1×128 |
| Operating Wavelength (nm) | 1260～1650 | ||||||
| Fiber Type | G657A or customer specified | ||||||
| Insertion Loss (dB) | 3.8 | 7 | 10.2 | 13.5 | 16.8 | 20.5/21.0 | 24.2/24.5 |
| Loss Uniformity (dB) | 0.4 | 0.5 | 0.8 | 1 | 1.2 | 2 | 2.5 |
| Return Loss (dB) | 55 | 55 | 55 | 55 | 55 | 55/50 | 55/50 |
| Polarization Dependent Loss(dB) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.35 | 0.35 |
| Directivity (dB) | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| Wavelength Dependent Loss(dB) | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.5 | 0.5 |
| Temperature Stability (-50～ 85 ℃)(dB) | 0.4 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 |
| Operating Temperature (℃) | -50～85 | ||||||
| Storage Temperature (℃) | -50～85 | ||||||
| Device Dimension (mm) (L×W×H) | 40×4×4 | 40×4×4 | 40×4×4 | 50×7×4 | 50×7×4 | 60×12×4 | 120x26x10 |
| Mini-Module Dimension (mm) (L×W×H) | 40×7×4 | 55×7×4 | 55×7×4 | 60×12×4 | 80×20×6 | 100X40X6 | 120x50x12 |
