Fiber Optic Indoor Patch Cord sc/upc-sc/upc

Description

Description

Indoor patch cords are current normal one. They are are used for the construction of horizontal subsystem and SCS building backbone cabling subsytems.

Features

• Full traceability and test certification supplied with each assembly.
• Ultra polish (UPC) supplied as standard and Angle polish (APC) also available.
• Qualified to Telcordia GR326 and IEC 61300 standards and RoHS co mpliant materials.properties.
• Can be supplied with many different connector types such as FC, SC, ST, E2000, LC, DIN and others on request.
• Available in singlemode and multimode (50/125 and 62.5/125).
• Many fibre types available including singlemode, multimode, low loss & bend insensitive fibres.
• Standard thickness, LC-LC(2m), LC-others (3m).
• All connectors are supplied with ceramic ferrules.

Application

• Data transmission
• Telecommunication
• Testing equipment
• WBN
• Optical fiber CATV
• LAN indoor/outdoor

  Module	x	xxx	x	x	xx	x	x	x	x
  YD-	Fiber Dia	Fiber Length	Fiber cores	Fiber model	Jacket	Input  Connector	Output  Connector	Fiber Stub	Strength Member
  IPC=Indoor Patch Cord APC/AP=Armored Patch Cord/Pigtail DPC=FTTH Drop Patch Cord CPC=CPRI Outdoor Patch Cord MPC/MP=Multicore Bundle Distribution Patch Cord/Pigtail OWP=Outdoor Waterproof Pigtail IP=Indoor Pigtail	0=250um	005=0.5m	01=Simplex	1=Single mode	PV=PVC	0=None	0=None	1=UPC	0=None
  	2=2.0mm	010=1.0m	02=Duplex		LS=LSZH	FC=FC	FC=FC	2=APC	1=Kevlar+Armored tube
  	3=3.0mm	015=1.5m	04=Quad	2=Multimode	OP=OFNP	SC=SC	SC=SC	3=PC
  	9=0.9mm Transparent	020=2.0m	06=6Core		OR=OFNR	LC=LC	LC=LC		2=Braid+Armored tube
  		030=3.0m	08=8Core		PE=PE	ST=ST	ST=ST
  	8=0.9mm Color	……	12=12Core		TP=TPU	MU=MU	MU=MU		3=Kevlar+Braid+Armored tube
  		300=30m	24=24Core			E2=E2000	E2=E2000
  			48=48Core			MT=MTP	MT=MTP		4=0.45mm steel wire
  			72=72Core			MP=MPT	MP=MPT
  			……			S=Specify	S=Specify		5=1.0mm steel wire
  			S=Specify
  									6=0.45mm FRP






  Module	x	xx	x	x	x	x	x	x
  YD-	Fiber Type	Fiber Length	Fiber cores	Fiber model	Connector	Fiber Stub	Jacket	Cable construction
  OWP=Outdoor Waterproof Pigtail IP=Indoor Pigtail	0=250um	05=0.5m	1=Simplex	1=Single mode	0=None	1=UPC	1=PE	1=Simplex
  	2=2.0mm	10=1.0m	2=Duplex	2=Multimode	1=FC	2=APC	2=other contracted material	2=multicore colorful
  	3=3.0mm	15=1.5m	3=Multicore		2=SC	3=PC
  	9=0.9mm Transparent	20=2.0m			3=LC			3=multicore bundle
  		30=3.0m			4=ST
  	8=0.9mm Color				5=MU			4=multicore distribution
  					6=E2000
  					S=Specify
